line

line LED Flex Strip
    Indoor, Waterproof
      CE RoHS
LED Flex

line
  SMD 3528 Indoor Strip
R3528 Strip
  • SMD3528 LED is directly mounted on flexible PCB,
  • With 3M self adhesive tape on the back ,facilitating easy installation.
  • Indoor Use

  • Voltage: DC12V or DC 24V;
  • LED type: SMD 3528.
  • LED QTY: 60LEDs/meter, 120LEDs/meter;
  • Color: Red, Yellow, Blue, Green, White, Warm white, Pink;
  • Packing: 5 meters/reel.

    		•
            60LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R3528R-12/24-60 Red 5000*6/8*2.2 60 12V/24V DC 4.80W non- waterproof 120
    LD-FLW-R3528Y-12/24-60 Yellow 60 12V/24V DC 4.80W 120
    LD-FLW-R3528B-12/24-60 Blue 60 12V/24V DC 4.80W 150
    LD-FLW-R3528G-12/24-60 Green 60 12V/24V DC 4.80W 240
    LD-FLW-R3528W-12/24-60 White 60 12V/24V DC 4.80W 390
    LD-FLW-R3528WW-12/24-60 Warm
    White    		 60 12V/24V DC 4.80W 360
            120LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R3528R-12/24-120 Red 5000*6/8*2.2 120 12V/24V DC 9.60W none waterproof 240
    LD-FLW-R3528Y-12/24-120 Yellow 120 12V/24V DC 9.60W 240
    LD-FLW-R3528B-12/24-120 Blue 120 12V/24V DC 9.60W 300
    LD-FLW-R3528G-12/24-120 Green 120 12V/24V DC 9.60W 480
    LD-FLW-R3528W-12/24-120 White 120 12V/24V DC 9.60W 780
    LD-FLW-R3528WW-12/24-120 Warm
    White    		 120 12V/24V DC 9.60W 720

      SMD3528 Silicone Cased Series Outdoor
    LED Flex
  • The LED Strip is covered by Silicone Housing.
  • IP67 Waterproof
  • Lighter weight
  • Easier cutting and rejoining

  • Voltage: DC12V or DC 24V;
  • LED type: SMD 3528.
  • LED QTY: 60LEDs/meter, 120LEDs/meter;
  • Color: Red, Yellow, Blue, Green, White, Warm white, Pink;
  • Packing: 5 meters/reel.
  • Size: 5000X10X4 mm
    		•
            60LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R3528R-12/24-60 Red 5000*6/8*2.2 60 12V/24V DC 4.80W IP66 120
    LD-FLW-R3528Y-12/24-60 Yellow 60 12V/24V DC 4.80W 120
    LD-FLW-R3528B-12/24-60 Blue 60 12V/24V DC 4.80W 150
    LD-FLW-R3528G-12/24-60 Green 60 12V/24V DC 4.80W 240
    LD-FLW-R3528W-12/24-60 White 60 12V/24V DC 4.80W 390
    LD-FLW-R3528WW-12/24-60 Warm
    White    		 60 12V/24V DC 4.80W 360
            120LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R3528R-12/24-120 Red 5000*6/8*2.2 120 12V/24V DC 9.60W IP66 240
    LD-FLW-R3528Y-12/24-120 Yellow 120 12V/24V DC 9.60W 240
    LD-FLW-R3528B-12/24-120 Blue 120 12V/24V DC 9.60W 300
    LD-FLW-R3528G-12/24-120 Green 120 12V/24V DC 9.60W 480
    LD-FLW-R3528W-12/24-120 White 120 12V/24V DC 9.60W 780
    LD-FLW-R3528WW-12/24-120 Warm
    White    		 120 12V/24V DC 9.60W 720

      SMD3528 Silicone Casted Series Outdoor
    LED Flex
  • fully silicone casted
  • Water proof, UP to IP67
  • Anti -UV rays, not become yellow even it is exposed to sun ray
  • Super performance in low temperature, flexible at even -20degree
  • Super transparent, looks elegent

  • Voltage: DC12V or DC 24V
  • LED type: SMD 3528
  • LED QTY: 60LEDs/meter, 120LEDs/meter
  • Color: Red, Yellow, Blue, Green, White, Warm white, Pink
  • Packing means: 5 meters/reel
    		•
            60LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R3528R-12/24-60 Red 5000*6/8*2.2 60 12V/24V DC 4.80W IP67 120
    LD-FLW-R3528Y-12/24-60 Yellow 60 12V/24V DC 4.80W 120
    LD-FLW-R3528B-12/24-60 Blue 60 12V/24V DC 4.80W 150
    LD-FLW-R3528G-12/24-60 Green 60 12V/24V DC 4.80W 240
    LD-FLW-R3528W-12/24-60 White 60 12V/24V DC 4.80W 390
    LD-FLW-R3528WW-12/24-60 Warm
    White    		 60 12V/24V DC 4.80W 360
            120LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R3528R-12/24-120 Red 5000*6/8*2.2 120 12V/24V DC 9.60W IP67 240
    LD-FLW-R3528Y-12/24-120 Yellow 120 12V/24V DC 9.60W 240
    LD-FLW-R3528B-12/24-120 Blue 120 12V/24V DC 9.60W 300
    LD-FLW-R3528G-12/24-120 Green 120 12V/24V DC 9.60W 480
    LD-FLW-R3528W-12/24-120 White 120 12V/24V DC 9.60W 780
    LD-FLW-R3528WW-12/24-120 Warm
    White    		 120 12V/24V DC 9.60W 720

    SMD5050 Indoor
    LED Flex
  • fully silicone casted
  • Water proof, UP to IP67
  • Anti -UV rays, not become yellow even it is exposed to sun ray
  • Super performance in low temperature, flexible at even -20degree
  • Super transparent, looks elegent
  • Voltage: DC12V or DC 24V
  • LED type: SMD 5050
  • LED QTY: 30LEDs/meter, 60LEDs/meter
  • Color: Red, Yellow, Blue, Green, White, Warm white, Pink
  • Packing means:5 meters/reel
    		•
            30LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R5050R-12-30 Red 5000*6/8*2.2 30 12V/24V DC 7.20W none waterproof 180
    LD-FLW-R5050Y-12-30 Yellow 30 12V/24V DC 7.20W 180
    LD-FLW-R5050B-12-30 Blue 30 12V/24V DC 7.20W 225
    LD-FLW-R5050G-12-30 Green 30 12V/24V DC 7.20W 360
    LD-FLW-R5050W-12-30 White 30 12V/24V DC 7.20W 450~585
    LD-FLW-R5050WW-12-30 Warm
    White    		 30 12V/24V DC 7.20W 360~540
    LD-FLW-R5050RGB-12-30 R 30 12V/24V DC 7.20W 60
    G 120
    B 75
            60LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R5050R-12-60 Red 5000*6/8*2.2 60 12V/24V DC 14.40W none waterproof 360
    LD-FLW-R5050Y-12-60 Yellow 60 12V/24V DC 14.40W 360
    LD-FLW-R5050B-12-60 Blue 60 12V/24V DC 14.40W 450
    LD-FLW-R5050G-12-60 Green 60 12V/24V DC 14.40W 720
    LD-FLW-R5050W-12-60 White 60 12V/24V DC 14.40W 900~1170
    LD-FLW-R5050WW-12-60 Warm
    White    		 60 12V/24V DC 14.40W 720~1080
    LD-FLW-R5050RGB-12-60 R 60 12V/24V DC 14.40W 120
    G 240
    B 150

    SMD5050 Silicone Casted Outdoor
    LED Flex
  • fully silicone casted
  • Water proof, UP to IP67
  • Anti -UV rays, not become yellow even it is exposed to sun ray
  • Super performance in low temperature, flexible at even -20degree
  • Super transparent, looks elegent

  • Voltage: DC12V or DC 24V
  • LED type: SMD 5050
  • LED QTY: 30LEDs/meter, 60LEDs/meter
  • Color: Red, Yellow, Blue, Green, White, Warm white, Pink
  • Packing means:5 meters/reel
    		•
            30LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R5050R-12-30 Red 5000*6/8*2.2 30 12V/24V DC 7.20W IP67 180
    LD-FLW-R5050Y-12-30 Yellow 30 12V/24V DC 7.20W 180
    LD-FLW-R5050B-12-30 Blue 30 12V/24V DC 7.20W 225
    LD-FLW-R5050G-12-30 Green 30 12V/24V DC 7.20W 360
    LD-FLW-R5050W-12-30 White 30 12V/24V DC 7.20W 450~585
    LD-FLW-R5050WW-12-30 Warm
    White    		 30 12V/24V DC 7.20W 360~540
    LD-FLW-R5050RGB-12-30 R 30 12V/24V DC 7.20W 60
    G 120
    B 75
            60LEDs/meter
    Item Number Color Dimension
    (mm)    		 Nos of
    LED per
    Meter    		 Working
    Voltage    		 Power
    per
    Meter    		 IP
    Rating    		 Lumen
    per
    Meter
    LD-FLW-R5050R-12-60 Red 5000*6/8*2.2 60 12V/24V DC 14.40W IP67 360
    LD-FLW-R5050Y-12-60 Yellow 60 12V/24V DC 14.40W 360
    LD-FLW-R5050B-12-60 Blue 60 12V/24V DC 14.40W 450
    LD-FLW-R5050G-12-60 Green 60 12V/24V DC 14.40W 720
    LD-FLW-R5050W-12-60 White 60 12V/24V DC 14.40W 900~1170
    LD-FLW-R5050WW-12-60 Warm
    White    		 60 12V/24V DC 14.40W 720~1080
    LD-FLW-R5050RGB-12-60 R 60 12V/24V DC 14.40W 120
    G 240
    B 150
      *Remark: Please advise the working voltage when order. 12V DC is default.
                         We have white PCB and brown PCB for options.
